Product Details:

Place of Origin: China
Brand Name: Vector
Certification: CE
Model Number: VEC-VC-01633H-M-E

Payment & Shipping Terms:

Minimum Order Quantity: 1 kit
Price: USD 400-650 / kit
Packaging Details: 280*208*78mm,375*290*155mm
Delivery Time: 3-5 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 500 kits/month
Get Best Price Contact Now

Detail Information

Voltage: 220V/380V Power: 7.5 KW
Phase: 3 Phase Communication Protocols: Modbus/CANopen/EtherCAT
Encoder: 17/23, 24 Bit Current: 16A
High Light:

7.5KW 16A AC Servo Drive

,

High Power 16A AC Servo Drive

,

7.5KW Servo Motor Drive

Product Description

7.5KW High Power Servo Motor Drive Fast Response Programmable AC Servo Drive 17/23,24Bit

Vector Tech. Focus on Servo system for more than 17 years.

More Flexible, More Accurate

Servo Drive

Power Covers 200W-110KW

Single/Three Phase 220V/380V

Modbus / CanOpen / EtherCAT

Location, Speed and Torque Control Mode

2500 line incremental + Hall encoder; 2500 line incremental; 17/23 bit Tamagawa absolute encoder;
24 bit Nikon absolute encoder



Products Description



Products AC Servo Drive
Brand Vector
Model No. VEC-VC-01633H-M-E
Power 7.5KW
Voltage 380V
Phase Three Phase
Rated Current 16A
Communication Protocols Modbus/CANopen/EtherCAT
Encoder 2500 line incremental + Hall encoder; 2500 line incremental; 17/23 bit Tamagawa absolute encoder;
24 bit Nikon absolute encoder



How is the Servo Drive works? The Location control model, Speed control model and Trogue control model.

Voltage Control Mode Single-phase / three-phase full-controlled rectification
SVPWM modulation
Encoder Encoder Feedback 2500 pulse incremental + Hall encoder;
2500 pulse incremental;
17bit Tamagawa absolute encoder;
23bit Tamagawa absolute encoder;
24bit Nikon absolute encoder;
Pulse Command Input Pulse Type Differential input,Open collector
Frequency Range Differential input:0-500kHz,pulse width greater than 1us
Open collector: 0-300kHz,pulse width greater than 2.5us
Pulse Mode pulse + direction; AB pluses; CW+CCW;
Analog Input Voltage Range -10V to 10V
Input Impedance 10kΩ
Maximum Frequency 1.5kHz
DI/DO Interface Type NPN/PNP
Communication Modbus/CANopen/EtherCAT





Position Mode Command Input Method Pulse Command
Internal Planning Position

> Plan by target position, speed, acceleration and deceleration
time

> Trapezoidal speed curve
> Cubic speed curve
> Absolute / relative command mode
Instruction Smoothing Mode Low Pass Filtering / Median Filtering
Electronic Gear Ratio N/M;(M=1~2147483647,N=1~2147483647)
Torque Limit Internal Torque Limit / Analog Torque Limit
Feedforward Compensation Speed Feedforward / Torque Feedforward
Torque Compensation Fixed Torque Compensation / Analog Torque Compensation /
Automatic Torque Compensation;
Speed Contol Mode Command Input Type Pulse Frequency / Analog / Internal Planning Speed
Speed Control Range 1~max speed
Bandwidth 1kHz
Torque Limit Internal Torque Limit / Analog Torque Limit
Instruction Smoothing Mode Low Pass Filtering / Median Filtering
Feedforward Compensation Torque feedforward
Torque Compensation Fixed Torque Compensation / Analog Torque Compensation /
Automatic Torque Compensation;
Torque Control Mode Command Input Type Internal Torque Reference / Analog Control Torque
Torque Compensation Fixed Torque Compensation / Analog Torque Compensation /
Automatic Torque Compensation;
Speed Limit Internal Speed Limit / Analog Speed Limit



Servo Drive Description- Detaails about a Servo Drive, how to select the Servo drive model and do installation?

7.5KW 16A AC Servo Drive High Power Servo Motor Drive 0

7.5KW 16A AC Servo Drive High Power Servo Motor Drive 1





7.5KW 16A AC Servo Drive High Power Servo Motor Drive 2

7.5KW 16A AC Servo Drive High Power Servo Motor Drive 3


Accessories

7.5KW 16A AC Servo Drive High Power Servo Motor Drive 4

Certificates

7.5KW 16A AC Servo Drive High Power Servo Motor Drive 5

Delivery Time and Shipping Way



Quantity 1-5 kits 50-100 kits 200-500 kits
Delivery time Within 3 days  5-10 days 15-25 days



1. For small order we always can delivery out within 1 week.

2. Our products can be shippied via Air, Land or Sea.
